And today's episode is about fractals.
In mathematics,
A fractal is a geometric shape containing detailed structure at arbitrarily small scales.
Usually having a fractal dimension strictly exceeding the topological dimension.
Many fractals appear similar at various scales,
As illustrated in successive magnifications of the Mandelbrot set.
This exhibition of similar patterns at increasingly smaller scales is called self-similarity.
Also known as expanding symmetry or unfolding symmetry.
If this replication is exactly the same at every scale as in the Menger sponge,
The shape is called a fine self-similar.
Fractal geometry relates to the mathematical branch of measure theory by their Hausdorff dimension.
One way that fractals are different from other geometric figures is how they scale.
Doubling the edge lengths of a filled polygon multiplies its area by 4,
Which is 2 raised to the power of 2.
Likewise,
If the radius of a filled sphere is doubled,
Its volume scales by 8,
Which is 2 to the power of 3.
However,
If a fractal's one-dimensional lengths are all doubled,
The spatial content of the fractal scales by a power that is not necessarily an integer,
And is in general greater than its conventional dimension.
This power is called the fractal dimension of the geometric object to distinguish it from the conventional dimension.
Analytically,
Many fractals are nowhere differentiable.
An infinite fractal curve can be conceived of as winding through space differently from an ordinary line.
Although it is still topologically one-dimensional,
Its fractal dimension indicates that it locally fills space more efficiently than an ordinary line.
Starting in the 17th century with notions of recursion,
Fractals have moved through increasingly rigorous mathematical treatment to the study of continuous but not differentiable functions in the 19th century by the seminal work of Bernard Bolzano,
Bernhard Riemann,
And Karl Weierstrass.
And on to the coining of the word fractal in the 20th century,
With a subsequent burgeoning of interest in fractals and computer-based modeling in the 20th century.
There is some disagreement among mathematicians about how the concept of a fractal should be formally defined.
In 1982,
Mendelbrot defined fractals as follows.
A fractal is by definition a set for which the Hausdorff-Besicovitch dimension strictly exceeds the topological dimension.
Later,
Seeing this as too restrictive,
He simplified and expanded the definition to this.
A fractal is a rough or fragmented geometric shape that can be split into parts,
Each of which is,
At least approximately,
A reduced-size copy of the whole.
Still later,
Mendelbrot proposed to use fractal without a pedantic definition,
To use fractal dimension as a generic term applicable to all the variants.
The consensus among mathematicians is that theoretical fractals are infinitely self-similar iterated and detailed mathematical constructs,
Of which many examples have been formulated and studied.
Fractals are not limited to geometric patterns,
But also describe processes in time.
Fractal patterns,
With various degrees of self-similarity,
Have been rendered or studied in visual,
Physical,
And oral media,
And found in nature,
Technology,
Art,
And architecture.
Fractals are of particular relevance in the fields of chaos theory,
Because they show up in the geometric depictions of most chaotic processes,
Typically either as attractors or as boundaries between basins of attraction.
The term fractal was coined by the mathematician Benoit Mendelbrot in 1975.
Mendelbrot based it on the Latin fractus,
Meaning broken or fractured,
And used it to extend the concept of theoretical fractional dimensions to geometric patterns in nature.
The word fractal often has different connotations for mathematicians and the generic public,
Where the public is more likely to be familiar with fractal art than the mathematical concept.
The mathematical concept is difficult to define formally,
Even for mathematicians,
But key features can be understood with a little mathematical background.
The feature of self-similarity,
For instance,
Is easily understood by analogy to zooming in with a lens,
Or other device that zooms in on digital images,
To uncover finer,
Previously invisible new structure.
If this is done on fractals,
However,
No new detail appears,
Nothing changes,
And the same pattern repeats over and over,
Or for some fractals,
Nearly the same pattern reappears over and over.
Self-similarity itself is not necessarily counterintuitive.
The difference for fractals is that the pattern reproduced must be detailed.
This idea of being detailed relates to another feature that can be understood without much mathematical background.
Having a fractal dimension greater than its topological dimension,
For instance,
Refers to how a fractal scales compared to how geometric shapes are usually perceived.
A straight line,
For instance,
Is conventionally understood to be one-dimensional.
If such a figure is reptiled into pieces,
Each one-third the length of the original,
Then there are always three equal pieces.
A solid square is understood to be two-dimensional,
If such a figure is reptiled into pieces,
Each scaled down by a factor of one-third,
In both dimensions.
There are a total of three to the power of two,
Equaling nine pieces.
We see that for ordinary self-similar objects,
Being n-dimensional means that when it is reptiled into pieces,
Each scaled down by a scale factor of one over r,
There are a total of r to the power of n pieces.
Now consider the Koch curve.
It can be reptiled into four sub-copies,
Each scaled down by a scale factor of one-third.
So,
Strictly by analogy,
We can consider the dimension of the Koch curve as being the unique real number d that satisfies three to the power of d,
Equaling four.
This number is called the fractal dimension of the Koch curve.
It is not the conventionally perceived dimension of a curve.
In general,
A key property of fractals is that the fractal dimension differs from the conventionally understood dimension,
Formerly called the topological dimension.
This also leads to understanding a third feature,
That fractals as mathematical equations are nowhere differentiable.
In a concrete sense,
This means fractals cannot be measured in traditional ways.
To elaborate,
In trying to find the length of a wavy non-fractal curve,
One could find straight segments of some measuring tool small enough to lay end-to-end over the waves,
Where the pieces could get small enough to be considered to conform to the curve in the normal manner of measuring with a tape measure.
But in measuring an infinitely wiggly fractal curve such as the Koch snowflake,
One would never find a small enough straight segment to conform to the curve.
Because the jagged pattern would always reappear at arbitrarily small scales,
Essentially pulling a little more of the tape measure into the total length measured each time when attempted to fit it together and tighter to the curve.
The result is that one must need infinite tape to perfectly cover the entire curve,
I.
E.
The snowflake has an infinite perimeter.
The history of fractals traces a path from chiefly theoretical studies to modern applications in computer graphics,
With several notable people contributing canonical fractal forms along the way.
A common theme in traditional African architecture is the use of fractal scaling,
Whereby small parts of the structure tend to look similar to larger parts,
Such as a circular village made of circular houses.
According to Pickover,
The mathematics behind fractals began to take shape in the 17th century,
When the mathematician and philosopher Gottfried Leibniz pondered recursive self-similarity.
In his writings,
Leibniz used the term fractional exponents,
But lamented that geometry did not yet know of them.
Indeed,
According to various historical accounts,
After that point,
Few mathematicians tackled the issue,
And the work of those who did remained obscured largely because of resistance to such unfamiliar emerging concepts,
Which were sometimes referred to as mathematical monsters.
Thus,
It was not until two centuries had passed that on July 18,
1872,
Karl Weierstrass presented the first definition of a function with a graph that would today be considered a fractal.
Having the non-intuitive property of being everywhere continuous,
But nowhere differentiable at the Royal Prussian Academy of Sciences.
In addition,
The quotient differences becomes arbitrarily large as the summation index increases.
Not long after that,
In 1883,
Georg Cantor,
Who attended lectures by Weierstrass,
Published examples of subsets of the real line known as Cantor sets,
Which had unusual properties and are now recognized as fractals.
Also in the last part of the century,
Felix Klein and Henri Poincaré introduced a category of fractal that has come to be called self-inverse fractals.
One of the next milestones came in 1904,
When Helga von Koch,
Extending ideas of Poincaré,
And dissatisfied with Weierstrass's abstract and analytic definition,
Gave a more geometric definition,
Including hand-drawn images of a similar function.
Which is now called the Koch snowflake.
Another milestone came a decade later in 1915,
When Wacław Szepiński constructed his famous triangle,
Then,
One year later,
His carpet.
By 1918,
Two French mathematicians,
Pierre Fatot and Gaston Julia,
Though working independently,
Arrived essentially simultaneously at results describing what is now seen as fractal behavior,
Associated with mapping complex numbers,
And iterative functions,
And leading to further ideas about attractors and repellers,
Which have become very important in the study of fractals.
Very shortly after that work was submitted,
By March 1918,
Felix Hausdorff expanded the definition of dimension,
Significantly for the evolution of the definition of fractals,
To allow for sets to have non-integer dimensions.
The idea of self-similar curves was taken further by Paul Levy,
Who in his 1938 paper Plane or Space Curves and Surfaces Consisting of Parts Similar to the Whole described a new fractal curve,
The Levy-C curve.
Different researchers have postulated that without the aid of modern computer graphics,
Early investigators were limited to what they could depict in manual drawings,
So lacked the means to visualize the beauty and appreciate some of the implications of many of the patterns they had discovered.
That changed,
However,
In the 1960s,
When Benoit Mandelbrot started writing about self-similarity in papers,
Such as How Long is the Coast of Britain?
Statistical Self-Similarity in Fractional Dimension,
Which built on earlier work by Louis Fry Richardson.
In 1975,
Mandelbrot solidified hundreds of years of thought and mathematical development in coining the word fractal and illustrating his mathematical definition with striking computer-constructed visualizations These images,
Such as of his canonical Mandelbrot set,
Captured the popular imagination.
Many of them were based on recursion,
Leading to the popular meaning of the term fractal.
In 1980,
Lorne Carpenter gave a presentation at the SIGGRAPH where he introduced his software for generating and rendering fractally generated landscapes.
One often-cited description that Mandelbrot published to describe geometric fractals is a rough or fragmented geometric shape that can be split into parts,
Each of which is at least approximately a reduced-size copy of the whole.
This is generally helpful,
But limited.
Authors disagree on the exact definition of fractal,
But most usually elaborate on the basic ideas of self-similarity and the unusual relationship fractals have with the space they are embedded in.
One point agreed on is that fractal patterns are characterized by fractal dimensions.
But whereas these numbers quantify complexity,
They neither uniquely describe nor specify details of how to construct particular fractal patterns.
In 1975,
When Mandelbrot coined the word fractal,
He did so to denote an object whose Hausdorff-Besicovitch dimension is greater than its topological dimension.
However,
This requirement is not met by space-filling curves,
Such as the Hilbert curve.
Because of the trouble involved in finding one definition for fractals,
Some argue that fractals should not be strictly defined at all.
According to Falconer,
Fractals should be only generally characterized by a gestalt of the following features.
Self-similarity,
Which may include exact self-similarity,
Identical at all scales,
Such as the Koch snowflake.
Quasi-self-similarity,
Approximates the same pattern at different scales,
May contain small copies of the entire fractal and distorted and degenerate forms,
E.
G.
The Mandelbrot set's satellites are approximations of the entire set,
But not exact copies.
Statistical self-similarity,
Repeats a pattern stochastically so numerical or statistical measures are preserved across scales,
E.
G.
Randomly generated fractals,
Like the well-known example of the coastline of Britain.
For which one would not expect to find a segment scaled and repeated,
As neatly as the repeated unit that defines fractals like the Koch snowflake.
Qualitative self-similarity,
As in a time series.
Multi-fractal scaling,
Characterized by more than one fractal dimension or scaling rule.
Fine or detailed structure at arbitrarily small scales.
A consequence of this structure is fractals may have emergent properties.
Irregularity locally and globally,
That cannot easily be described in the language of traditional Euclidean geometry,
Other than as a limit of a recursively defined sequence of stages.
For images of fractal patterns,
This has been expressed by phrases such as smoothly piling up surfaces and swirls upon swirls.
As a group,
These criteria form guidelines for excluding certain cases,
Such as those that may be self-similar without having other typically fractal features.
A straight line,
For instance,
Is self-similar,
But not fractal because it lacks detail,
And is easily described in Euclidean language without a need for recursion.
When Mandelbrot introduced the term fractal,
He excluded magnification range as a defining characteristic in order to accommodate physical fractals with more limited ranges than their mathematical counterparts.
Images of fractals can be created by fractal generating programs.
Because of the butterfly effect,
A small change in a single variable can have an unpredictable outcome.
Iterated function systems,
IFS,
Use fixed geometric replacement rules,
May be stochastic or deterministic,
E.
G.
Koch snowflake,
Cantor's head,
Hufferman carpet,
Sierpinski carpet,
Sierpinski gasket,
Pinot curve,
Harter highway dragon curve,
T-square,
Menger sponge.
Strange attractors use iterations of a map or solutions of a system of initial value differential or difference equations that exhibit chaos.
L-systems use string rewriting,
May resemble branching patterns such as in plants,
Biological cells,
Blood vessels,
Pulmonary structure,
Or turtle graphics patterns,
Such as space-filling curves and tilings.
Escape-time fractals use a formula or recurrence relation at each point in a space,
Such as the complex plane,
Usually quasi-self-similar,
Also known as orbit fractals,
E.
G.
The Mandelbrot set,
Julia set,
Burning Ship fractal,
Nova fractal,
And Lyapunov fractal.
The 2D vector fields that are generated by one or two iterations of escape-time formulae also give rise to a fractal form when points are passed through this field repeatedly.
Random fractals use stochastic rules,
E.
G.
Levy flight,
Percolation clusters,
Self-avoiding walks,
Fractal landscapes,
Trajectories of Brownian motion,
And the Brownian tree.
Fractal patterns have been modeled extensively,
Albeit within a range of scales rather than infinitely,
Owing to the practical limits of physical time and space.
Models may simulate theoretical fractals or natural phenomena with fractal features.
The outputs of the modeling process may be highly artistic renderings,
Outputs for investigation,
Or benchmarks for fractal analysis.
Some specific applications of fractals to technology are listed elsewhere.
Images and other outputs of modeling are normally referred to as being fractals,
Even if they do not have strictly fractal characteristics,
Such as when it is possible to zoom into a region of the fractal image that does not exhibit any fractal properties.
Also,
These may include calculation or display artifacts which are not characteristics of true fractals.
Modeled fractals may be sounds,
Digital images,
Electrochemical patterns,
Circadian rhythms.
Fractal patterns have been reconstructed in physical three-dimensional space and virtually,
Often called in silico modeling.
Models of fractals are generally created using fractal generating software.
As one illustration,
Trees,
Ferns,
Cells of the nervous system,
Blood and lung vasculature,
And other branching patterns in nature can be modeled on a computer by using recursive algorithms and L-systems techniques.
The recursive nature of some patterns is obvious in certain examples.
A branch from a tree,
Or a frond from a fern,
Is a miniature replica of the whole,
Not identical,
But similar in nature.
Similarly,
Random fractals have been used to describe or create many highly irregular real-world objects,
Such as coastlines and mountains.
A limitation of modeling fractals is that resemblance of a fractal model to a natural phenomenon does not prove that the phenomenon being modeled is formed by a process similar to the modeling algorithms.
Approximate fractals found in nature display self-similarity over extended but finite scale ranges.
The connection between fractals and leaves,
For instance,
Is currently being used to determine how much carbon is contained in trees.
Fractals often appear in the realm of living organisms,
Where they arise through branching processes and other complex pattern formation.
Richard Taylor and co-workers have shown that the dendritic branches of neurons form fractal patterns.
Ian Wong and co-workers have shown that migrating cells can form fractals by clustering and branching.
Nerve cells function through processes at the cell surface,
With phenomena that are enhanced by largely increasing the surface-to-volume ratio.
As a consequence,
Nerve cells often are found to form in diffractal patterns.
These processes are crucial in cell physiology and different pathologies.
Multiple subcellular structures also are found to assemble in diffractals.
Diego Krapf has shown that through branching processes,
The actin filaments in human cells assemble into fractal patterns.
Similarly,
Masias Weiss showed that the endoplasmic reticulum displays fractal features.
The current understanding is that fractals are ubiquitous in cell biology,
From proteins,
To organelles,
To whole cells.
